Giant Bicycles

CADEX 40 Max Wheels

CADEX 40 Max Wheels

Regular price $2,000.00 USD
Regular price $2,000.00 USD Sale price $2,000.00 USD
Sale Sold out
Option
  • Integrated spoke, hub flange and aero hub design for optimal weight savings, better power transfer, and improved aerodynamics.
  • CADEX hookless rim technology with optimized carbon layup improves durability and tire performance at a superlight weight.
  • High-tensile-strength integrated CADEX Super Aero spokes with hidden nipples and independent internal spoke tension adjustment minimize lateral flex for more
    efficient acceleration and climbing.
  • Dynamic Balanced Lacing technology sets spokes at a wider bracing angle to stabilize spoke tension levels under pedaling force, producing a stiffer, more efficient wheel with outstanding power transfer.
  • 48-tooth ratchet engagement in the CADEX R3-C48 Aero Hub offers more immediate power transfer.
  • CADEX Ratchet Wave Spring ensures the outer and inner ratchet rings engage with consistent and even force for smoother action and better rolling efficiency.
  • Broad 22.4mm inner rim width creates a rounder tire profile and increased tire contact patch for better sidewall support, improved handling, and less rider fatigue.
  • 40mm rim profile delivers exceptional stability and aero benefits for all-day efforts.
  • In-mold carbon surface graphic technology blends CADEX logos into the carbon rim surface without the need for etching or decals.

Specifications


Rim Material: Carbon

Rim Type: Hookless

Tubeless: CADEX Tubeless System (rim tape and valve kit included)

Suggested Tire Size: 700 x 25C – 700 x 32C

Rim Height: 40mm

Rim Outer Width: 28mm

Rim Inner Width: 22.4mm

ETRTO: 622-22

Front Hub: CADEX R3 , Centerlock One-piece integrated hub and spokes

Rear Hub: CADEX R3-C48, Ratchet Driver, Centerlock One-piece integrated hub and spokes

Hub Compatibility: Shimano / SRAM XDR / Campagnolo N3W

Bearings: Ceramic

Front Axle: 100x12mm Thru Axle

Rear Axle: 142x12mm Thru Axle

Front Spokes: Super Aero Carbon Spoke

Front Lacing: DBL, 16H

Rear Spokes: Super Aero Carbon Spoke

Rear Lacing: DBL, 24H

Nipple: Hidden Integrated Alloy Nipple

Warranty: Lifetime (for registered original owners)

Incident Replacement: 5 years (for registered original owners)

Weight (Pair): 1249g (with Shimano freehub)
